GS-4210-24T4S / GS-4210-24T4SR - Planet Managed Gigabit Switch

Mã sản phẩm: GS-4210-24T4S / GS-4210-24T4SR

Tình trạng: Còn hàng

Thương hiệu: PLANET

GS-4210-24T4S / GS-4210-24T4SR - Planet Managed Gigabit Switch

Hỗ trợ kinh doanh

Ms. Lan
0971156699
Ms.Thương
0824889876

Hỗ trợ kỹ thuật

Mr. Kỳ
0383791490

Liên hệ nhận giá tốt

Thông số kỹ thuật

Hardware Specifications
Copper Ports	24 x 10/100/1000BASE-T RJ45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots	4 x 100/1000BASE-X SFP interfaces with Port-25 to Port-28. Supports 100/1000Mbps dual mode and DDM
Console	1 x RS-232-to-RJ45 serial port (115200, 8, N, 1)
Reset Button	< 5 sec: System reboot > 5 sec: Factory default
Dimensions (W x D x H)	441 x 207 x 44 mm, 19-inch, 1U height
Weight	GS-4210-24T4S: 2.1kg GS-4210-24T4SR: 2.1 kg
ESD Protection	Contact Discharge 4KV DC Air Discharge 8KV DC
Enclosure	Metal
Power Requirements	GS-4210-24T4S: AC 100~240V, 50/60Hz, auto-sensing GS-4210-24T4SR: AC 100~240V, 50/60Hz, auto-sensing DC 36-72V
Power Consumption / Dissipation	GS-4210-24T4S: 19.3 watts (max.)/65BTU GS-4210-24T4SR: AC: 19.3 watts (max.)/65BTU DC: 19.2 watts (max.)/65BTU
LED	System: Power (Green) 10/100/1000T RJ45 Interfaces (Port 1 to Port 24): 1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange) 100/1000Mbps SFP Interfaces (Port 25 to Port 28): 1000 LNK/ACT (Green), 100 LNK/ACT (Orange)
Switching
Switch Architecture	Store-and-Forward
Switch Fabric	56Gbps/non-blocking
Switch Throughput@64Bytes	41.67Mpps
Address Table	8K entries
Shared Data Buffer	4.1 megabits
Flow Control	IEEE 802.3x pause frame for full-duplex Back pressure for half-duplex
Jumbo Frame	10K bytes
