Mã sản phẩm: GS-4210-24UP4C
Tình trạng: Còn hàng
Thương hiệu: PLANET
GS-4210-24UP4C - Planet Combo Managed Switch
Hỗ trợ kinh doanh
Ms. Lan
Mr Ánh
Ms Mỹ
Mr Liêm
Hỗ trợ kỹ thuật
Mr. Kỳ
Mr Toàn
Mr Hoàng
Mr Công
Liên hệ nhận giá tốt
Thông số kỹ thuật
GS-4210-24UP4C - Planet Combo Managed Switch
Hardware Specifications | |
---|---|
Copper Ports | 28 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port |
SFP Slots | 4 x 100/1000BASE-X SFP interface shared with port-25 to port-28 Supports 100/1000Mbps dual mode and DDM |
PoE Injector Port | 24 ports with 802.3at/af/802.3bt PoE++ injector function with port-1 to port-24 |
Switch Architecture | Store-and-Forward |
Switch Fabric | 56Gbps/non-blocking |
Switch Throughput@64Bytes | 41.67Mpps |
Address Table | 8K entries |
Shared Data Buffer | 4.1 megabits |
Flow Control | IEEE 802.3x pause frame for full duplex Back pressure for half duplex |
Jumbo Frame | 10K bytes |
Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
LED | System: PWR x1 (Green) SYS x1 (Green) Per PoE Port (Port 1 to Port 24): 10/100/1000 LNK/ACT x1 (10/100:Orange.1000:Green) IEEE 802.3af/at/bt PoE-in-use x1 (802.3af/at: Orange. 802.3bt: Green) Per Gigabit TP Port (Port 25 to Port 28): 10/100 LNK/ACT x1 (Orange) 1000 LNK/ACT x1 (Green) Per Gigabit SFP Port (Port 25 to Port 28): 100 LNK/ACT x1 (Orange) 1000 LNK/ACT x1 (Green) Alert: PoE PWR x1 (Red) FAN1 x1 (Red) FAN2 x1 (Red) FAN3 x1 (Red) |
Power Requirements | 100~240V AC, 50/60Hz, auto-sensing |
Dimensions (W x D x H) | 440 x 300 x 44.5 mm, 1U height |
ESD Protection | Contact Discharge 4KV DC Air Discharge 8KV DC |
Enclosure | Metal |
Weight | 5kg |
Power Consumption/Dissipation | 900 watts (max.)/3070 BTU |
Fan | 3 x smart fan |
Power over Ethernet | |
PoE Standard | IEEE 802.3bt PoE++ PSE Backward compatible with IEEE 802.3at/af PoE PSE |
PoE Power Supply Type | ■ 802.3bt ■ UPoE/POH ■ End-span ■ Mid-span ■ Force |
PoE Power Output | Per port 54V DC ■ 802.3bt mode, Ports 1 to 8: maximum 90 watts ■ 802.3bt mode, Ports 9 to 24: maximum 60 watts ■ UPoE mode, Ports 1 to 8: maximum 95 watts ■ UPoE-mode, Ports 9 to 24: maximum 72 watts ■ End-span mode: maximum 36 watts ■ Mid-span mode: maximum 36 watts |
Power Pin Assignment | ■ 802.3bt: 1/2(-), 3/6(+), 4/5(+), 7/8(-) ■ UPoE: 1/2(-), 3/6(+), 4/5(+), 7/8(-) ■ End-span: 1/2(-), 3/6(+) ■ Mid-span: 4/5(+), 7/8(-) |
PoE Power Budget | 720 watts, operating temperature < 40 degrees C 660 watts, operating temperature between 40 to 49 degrees C 600 watts, operating temperature around 50 degrees C (Factory default mode) |
Number of 90W 802.3bt Type-4 PDs | 8 |
Number of 60W 802.3bt Type-3 PDs | 12 |
Number of 802.3at PDs | 24 |
