GS-5220-24UPL4XVR - Planet L3 24-Port 10/100/1000T 802.3bt PoE + 4-Port 10G SFP+ Managed Switch with LCD Touch Screen

Tình trạng: Còn hàng

Giá: Liên hệ

Chi tiết: Planet L3 24-Port 10/100/1000T 802.3bt PoE + 4-Port 10G SFP+ Managed Switch with LCD Touch Screen

Liên hệ nhận giá tốt

Tùy chọn

Thông số kỹ thuật

GS-5220-24UPL4XVR - Planet L3 24-Port 10/100/1000T 802.3bt PoE + 4-Port 10G SFP+ Managed Switch with LCD Touch Screen

Hardware Specifications
Copper Ports24 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
SFP+ Ports4 10GBASE-SR/LR SFP+ interfaces (Port-25 to Port-28)
Compatible with 1000BASE-SX/LX/BX and 2500BASE-X SFP transceiver
Console1 x RS232-to-RJ45 serial port (115200, 8, N, 1)
Reset Button< 5 sec: System reboot
> 5 sec: Factory default
Dimensions (W x D x H)440 x 300 x 56 mm, 1.25U height
Weight5478g
Power ConsumptionMax. 740 watts/ 2538.94 BTU
Power Requirements – ACAC 100~240V, 50/60Hz, 8A
Power Requirements – DCGS-5220-24UPL4XVR: DC 36~60V, 2A
ESD Protection6KV DC
Fan3 smart fans
LEDSystem:
 SYS (Green)
 AC (Green)
 DC (Green) for GS-5220-24UPL4XVR
 Ring (Green)
 Fan1/2/3 Alert (Red)
 PoE PWR Alert (Red)
PoE Ethernet Interfaces (Port-1 to Port-24):
 af/at PoE (Orange)
 bt PoE/UPOE (Green)
Ethernet Interfaces (Port-1 to Port-24):
 1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange)
1/10G SFP+ Interfaces (Port-27 to Port-28):
 1G/2.5G (Green), 10G (Orange)
Switching Specifications
Switch ArchitectureStore-and-Forward
Switch Fabric128Gbps/non-blocking
Throughput95.23Mpps@64Bytes
Address Table16K entries, automatic source address learning and aging
Shared Data Buffer32M bits
Flow ControlIEEE 802.3x pause frame for full duplex
Back pressure for half duplex
Jumbo Frame10K bytes
Power over Ethernet
PoE Standard802.3bt PoE++ PSE
Backward compatible with IEEE 802.3af/802.3at PoE PSE
PoE Power Supply Type802.3bt
UPoE
End-span
Mid-span
Force
PoE Power OutputPer port 52V DC
- 802.3bt Type-4 mode, Port-1 to Port-8: maximum 90 watts
- 802.3bt Type-3 mode, Port-9 to Port-24: maximum 60 watts
- UPoE mode, Port-1 to Port-8: maximum 95 watts
- UPoE-mode, Port-9 to Port-24: maximum 72 watts
- End-span mode: maximum 36 watts
- Mid-span mode: maximum 36 watts
- Force mode: maximum 60 watts
Power Pin Assignment802.3bt: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
UPoE: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
End-span: 1/2(-), 3/6(+)
Mid-span: 4/5(+), 7/8(-)
PoE Power BudgetGS-5220-24UPL4XVR: 600 watts (max.)
GS-5220-24UP4XV: 400 watts (max.)
PoE Ability PD @ 7 watts24 units
PoE Ability PD @ 15 watts20 units
PoE Ability PD @ 30 watts10 units
Layer 3 Functions
IP InterfacesMax. 128 VLAN interfaces
Routing TableMax. 128 routing entries
Routing ProtocolsIPv4 OSPFv2
IPv4 hardware static routing
IPv6 hardware static routing
Layer 2 Management Functions
Port ConfigurationPort disable/enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow control disable/enable
Port StatusDisplay each port’s speed duplex mode, link status, flow control status,
auto-negotiation status, trunk status
Port MirroringTX/RX/Both
Many-to-1 monitor
VLANIEEE 802.1Q tagged VLAN
IEEE 802.1ad Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN registration)
Up to 4K VLAN groups, out of 4095 VLAN IDs
Link AggregationIEEE 802.3ad LACP/static trunk
14 trunk groups with 4 ports per trunk
Spanning Tree ProtocolIEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
QoSTraffic classification based, strict priority and WRR
8-level priority for switching:
- Port number
- 802.1p priority
- 802.1Q VLAN tag
- DSCP/ToS field in IP packet
IGMP SnoopingIPv4 IGMP (v1/v2/v3) snooping
IPv4 IGMP querier mode support
Up to 255 multicast groups
MLD SnoopingIPv6 MLD (v1/v2) snooping
IPv6 MLD querier mode support
Up to 255 multicast groups
Bandwidth ControlPer port bandwidth control
Ingress: 100Kbps~1000Mbps
Egress: 100Kbps~1000Mbps
RINGSupports ERPS, and complies with ITU-T G.8032
Recovery time < 10ms
