Huawei CloudEngine S1730S-S48P4S-A

Tình trạng: Còn hàng

Giá: Liên hệ

Chi tiết: Huawei CloudEngine S1730S-S48P4S-A switch with 48-ports 1000BASE-T, 4-ports GE SFP, PoE+, 1 AC power fixed

Liên hệ nhận giá tốt

Tùy chọn

Thông số kỹ thuật

Bộ chia mạng Huawei CloudEngine S1730S-S48P4S-A switch with 48-ports 1000BASE-T, 4-ports GE SFP, PoE+, 1 AC power fixed chính hãng.

Mô tả Huawei CloudEngine S1730S-S48P4S-A

Huawei CloudEngine S1730S-S48P4S-A switch with 48-ports 4GE SFP

With 1 AC power fixed

PoE+ Supported

Forwarding performance: 77.38 Mpps

Switching capacity: 216 Gbps

Memory (RAM) 1 GB

Flash 512 MB in total



Huawei CloudEngine S1730 series switches are easy to install and maintain and come with a wide range of service features, helping customers build secure, reliable, and high-performance networks. There are two types of CloudEngine S1730S series switches: web-managed switches and fully-managed switches.

Thông số kỹ thuật

Specification
Fixed port48 x 10/100/1000Base-T Ethernet ports, 4 x GE SFP ports, PoE+
Rated voltage range100 V AC to 130 V AC, 200 V AC to 240 V AC; 50/60 Hz; High-voltage DC input: 240 V DC
Maximum voltage range90 V AC to 264 V AC, 47 Hz to 63 Hz; High-voltage DC input: 190 V DC to 290 V DC
Power supplyPluggable 1000 W AC power moduler
Maximum power consumptionWithout PoE: 75 W; 100% PoE loads: 911 W (PoE: 874 W)
Surge protectionPower port: ±6 kV in differential mode; ±6 kV in common mode; Service port: ±7 kV in common mode
Heat dissipationAir-cooled heat dissipation and intelligent speed adjustment
PortVLAN/Voice VLAN



Port bridge

Jumbo frames

Detect link

Flow control auto-negotiation

Traffic statistics collection on interfaces

Interface rate auto-negotiation

VLANIF interfaces MTU

Link aggregation

Static interface aggregation

SecurityPort security



Sticky MAC

Suppressing broadcast, multicast, and unknown unicast traffic on interfaces

Controlling broadcast, multicast, and unknown unicast storms

Port isolation

IPSG

ARP security

CPU security protection

Ethernet4K VLANs



Access modes of access, trunk, hybrid, and QinQ

Interface-based VLAN assignment

Interface-based MAC address learning

Static MAC address entry

Automatic aging of MAC addresses

STPSTP (IEEE 802.1d)



RSTP (IEEE 802.1w)

MSTP (IEEE 802.1s)

MulticastMulticast VLAN



Layer 2 multicast policy

IGMP V1/V2/V3 snooping

MLD V1/V2 snooping

Static multicast MAC address

RoutingDynamic routes



Static routes

ARP

ND

DNS client

QoSCAR



Traffic policing

Traffic shaping

Priority mapping

Queue scheduling

Congestion avoidance

IPv4 and IPv6 ACL

NACDHCP client



DHCP relay

DHCP server

DHCP snooping

DHCPv6 relay

802.1X authentication

MAC address authentication

Portal authentication

Terminal type identification

AAA

Device managementWeb system network management



Dormancy of electrical interfaces

Automatic power adjustment on Ethernet interfaces (802.3az)

Intelligent upgrade

Device maintenanceSystem log



Ping

Mirroring

Loopback detection

Virtual Cable Test (VCT)

Link Layer Discovery Protocol (LLDP)

NTP

CertificationEMC certification



Safety certification

Manufacturing certification

Dimensions (H x W x D)

43.6 mm x 442 mm x 420 mm



Thông tin bổ sung

Weight8.7 kg
Dimensions43.6 × 442.0 × 420.0 cm
PoE Type

PoE+

Port

48+

Rate

GE
