Huawei CloudEngine S3710-H24P4S-A

Tình trạng: Còn hàng

Giá: Liên hệ

Chi tiết: Huawei CloudEngine S3710-H24P4S-A (24*10/100/1000BASE-T ports, 4*GE SFP ports, PoE+, AC power)

Liên hệ nhận giá tốt

Tùy chọn

Thông số kỹ thuật

Thiết bị chuyển mạch Huawei CloudEngine S3710-H24P4S-A (24*10/100/1000BASE-T ports, 4*GE SFP ports, PoE+, AC power)

Thông số kỹ thuật Huawei CloudEngine S3710-H24P4S-A

ItemSpecification
Dimensions without packaging (H x W x D) [mm(in.)]

Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.)

Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)

Dimensions with packaging (H x W x D) [mm(in.)]90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Chassis height [U]1 U
Weight without packaging [kg(lb)]2.92 kg (6.44 lb)
Weight with packaging [kg(lb)]3.79 kg (8.36 lb)
Typical power consumption [W]32.46 W
Typical heat dissipation [BTU/hour]110.76 BTU/hour
Maximum power consumption [W]
  • Without PoE: 47.1 W
  • Full PoE load: 491.66 W (PoE: 400 W)
Maximum heat dissipation [BTU/hour]
  • Without PoE: 160.71
  • Full PoE load: 1677.59
Static power consumption [W]30.82 W
MTBF [year]60.18 year
MTTR [hour]2 hour
Availability>0.99999
Noise at normal temperature (acoustic power) [dB(A)]49.3 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)]37.3 dB(A)
Number of card slots0
Number of power slots0
Number of fans modules2
Redundant power supplyNot supported
Long-term operating temperature [°C(°F)]-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)
Restriction on the operating temperature variation rate [°C(°F)]

When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Devices cannot start when the temperature is lower than 0°C (32°F).

Storage temperature [°C(°F)]–40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH]5% RH to 95% RH (non-condensing)
Long-term operating altitude [m(ft.)]0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)]0-5000 m (0-16404 ft.)
Power supply modeAC built-in
Rated input voltage [V]AC input: 100–240 V AC; 50/60 Hz
Input voltage range [V]AC input: 90–290 V AC; 45–65 Hz
Maximum input current [A]6 A
Memory2 GB
Flash memory1 GB in total. To view the available flash memory size, run the display version command.
Console portRJ45
Eth Management portNot supported
USBNot supported
RTCNot supported
RPS inputNot supported
Service port surge protection [kV]Common mode: ±7 kV
Power supply surge protection [kV]Differential mode: ±6 kV; common mode: ±6 kV
Types of fansBuilt-in
Heat dissipation modeAir cooling for heat dissipation, intelligent fan speed adjustment
Airflow directionAir intake from left and front, air exhaustion from right
PoESupported
Certification

EMC certification

Safety certification

Manufacturing certification
