Huawei CloudEngine S3710-H48T4S-A

Mã sản phẩm: S3710-H48T4S-A

Tình trạng: Còn hàng

Thương hiệu: HUAWEI

Thiết bị chuyển mạch Huawei CloudEngine S3710-H48T4S-A (48*10/100/1000BASE-T ports, 4*GE SFP ports, AC power)

Hỗ trợ kinh doanh

Hỗ trợ kỹ thuật

Liên hệ nhận giá tốt

Thông số kỹ thuật

Thiết bị chuyển mạch Huawei CloudEngine S3710-H48T4S-A (48*10/100/1000BASE-T ports, 4*GE SFP ports, AC power)

Thông số kỹ thuật Huawei CloudEngine S3710-H48T4S-A

Product Model	CloudEngine S3710-H24P4S-A	CloudEngine S3710-H24T4S-A	CloudEngine S3710-H48LP4S-A	CloudEngine S3710-H48T4S-A
Forwarding Performance	42Mpps	42Mpps	78Mpps	78Mpps
Switching Capacity²	56Gbps/520Gbps	56Gbps/520Gbps	104Gbps/520Gbps	104Gbps/520Gbps
Fixed Ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports	24 x 10/100/1000Base-T ports, 4 x GE SFP ports	48 x 10/100/1000Base-T ports, 4 x GE SFP ports	48 x 10/100/1000Base-T ports, 4 x GE SFP ports
PoE	CloudEngine S3710-H24P4S-A：Supported CloudEngine S3710-H24T4S-A：Not supported CloudEngine S3710-H48LP4S-A：Supported CloudEngine S3710-H48T4S-A：Not supported
MAC Features	MAC address auto-learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses Interface-based MAC address learning limiting
VLAN Features	4094 VLANs Voice VLAN MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
Reliability	LACP, VRRP, BFD
Interoperability	VBST (compatible with PVST/PVST+/RPVST) LNP (similar to DTP) VCMP (similar to VTP)
