DS1522+

(5/5)

Đánh giá sản phẩm

DS1522+ Synology DiskStation DS1522+

Tình trạng: Còn hàng

Giá: Liên hệ

Chi tiết: Khe cắm M.2 NVMe tích hợp cho bộ nhớ đệm SSD 4 x 1 GbE và 1 x 10GbE RJ-45 tùy chọn Mở rộng quy mô lên đến 15 ổ

Liên hệ nhận giá tốt

Tùy chọn

Thông số kỹ thuật

Bộ lưu trữ DS1522+ Synology DiskStation DS1522+

CPU
CPU ModelAMD Ryzen R1600
 CPU Quantity1
 CPU Architecture64-bit
 CPU Frequency2-core 2.6 (base) / 3.1 (turbo) GHz
 Hardware Encryption Engine (AES-NI)
Memory
System Memory8 GB DDR4 ECC SODIMM
 Memory Module Pre-installed8 GB (8 GB x 1)
 Total Memory Slots2
 Maximum Memory Capacity32 GB (16 GB x 2)
 Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • Để biết thêm thông tin về cấu hình bộ nhớ đề xuất, vui lòng xem Hướng dẫn cài đặt phần cứng của sản phẩm Synology của bạn.
Storage
Drive Bays5
 Maximum Drive Bays with Expansion Unit15 (DX517 x 2)
 M.2 Drive Slots2 (NVMe)
 Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA SSD
  • M.2 2280 NVMe SSD
 Hot Swappable Drive
 Notes"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port*4 (with Link Aggregation / Failover support)
 USB 3.2 Gen 1 Port*2
 eSATA Port2
 Notes
  • This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
  • The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe
PCIe Expansion1 x Gen3 x2 network upgrade slot
File System
Internal Drives
  • Btrfs
  • EXT4
 External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT
Appearance
Size (Height x Width x Depth)166 mm x 230 mm x 223 mm
 Weight2.7 kg
Others
System Fan92 mm x 92 mm x 2 pcs
 Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
 Brightness Adjustable Front LED Indicators
 Power Recovery
 Noise Level*22.90 dB(A)
 Scheduled Power On / Off
 Wake on LAN / WAN
 Power Supply Unit / Adapter120 W
 AC Input Power Voltage100V to 240V AC
 Power Frequency50/60 Hz, Single Phase
 Power Consumption*52.06 W (Access)
16.71 W (HDD Hibernation)
 British Thermal Unit177.64 BTU/hr (Access)
57.02 BTU/hr (HDD Hibernation)
 Notes
  • Để biết thêm chi tiết cách đo mức tiêu thụ điện năng, tham khảo tại bài viết này.
  • Thử nghiệm tiếng ồn được tiến hành trên hệ thống Synology được cài đặt đầy đủ các ổ HDD Synology SATA và ở trạng thái nghỉ. Hai micrô 40AE loại G.R.A.S. được đặt cách mặt trước và mặt sau của thiết bị 1 m. Tiếng ồn xung quanh: 16,49-17,51 dB (A); Nhiệt độ: 24,25-25,75˚C; Độ ẩm: 58,2-61,8%
Temperature
Operating Temperature0°C to 40°C (32°F to 104°F)
 Storage Temperature-20°C to 60°C (-5°F to 140°F)
 Relative Humidity5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
Warranty
3-year hardware warranty, extendable to 5-year coverage - EW201
 NotesThe warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  • DDR4 ECC SODIMM: D4ES02-8G/D4ES01-16G
  • Expansion Units: DX517
  • 3.5" SATA HDD: HAT5300
  • 2.5" SATA SSD: SAT5210
  • M.2 2280 NVMe SSD: SNV3410
  • 10GbE Network Upgrade Module: E10G22-T1-Mini
  • VisualStation: VS360HD
  • Surveillance Device License Pack
