Huawei S2720-28TP-PWR-EI-L

Tình trạng: Còn hàng

Giá: Liên hệ

Chi tiết: Huawei S2720-28TP-PWR-EI-L switch with 16-ports 100BASE-Tx, 8-ports 1000BASE-T, 2-ports GE SFP, 2-ports GE SFP combo, 8-ports PoE+ 1 AC power fixed

Liên hệ nhận giá tốt

Tùy chọn

Thông số kỹ thuật

Bộ chuyển mạch Huawei S2720-28TP-PWR-EI-L switch with 16-ports 100BASE-Tx, 8-ports 1000BASE-T, 2-ports GE SFP, 2-ports GE SFP combo, 8-ports PoE+ 1 AC power fixed

Mô tả Huawei S2720-28TP-PWR-EI-L

Huawei S2720-28TP-PWR-EI-L switch, 16-ports 100BASE-Tx, 8-ports 1000BASE-T, 2-ports GE SFP, 2-ports GE SFP combo, 8-ports PoE+

With 1 AC power fixed

No extension slots

Layer 2 Ethernet switch

Forwarding perfomance: 20.4Mpps

Switching capacity: 68Gbps

16K MAC address entries

POE switch



Huawei Quidway S2700 series switches are intelligent access switches for telecom customers. The S2700 is mainly deployed on the intranets and IP Metropolitan Area Network, carrying various Ethernet services. Huawei S2700 supports powerful surge protection, SEP, ERPS, ASIC switching etc.

Thông số kỹ thuật Huawei S2720-28TP-PWR-EI-L

ItemDescription
Fixed port16 × Ethernet 10/100 Base-Tx ports, 8 × Ethernet 10/100/1000
Base-T ports, 2 × Gig SFP ports, 2 ×combo Gig ports, 8 ×PoE+ ports
MAC address table16K MAC address entries



MAC address learning and aging

Static, dynamic, and blackhole MAC address entries Interface-based MAC learning limiting

VLAN features4K VLANs



Guest VLAN and voice VLAN

GVRP

MUX VLAN

VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and interfaces 1:1 and N:1 VLAN mapping

Ethernet loop protectionRRPP ring topology and RRPP multi-instance



Smart Link tree topology and Smart Link multi-instance, providing millisecond-level

protection switchover

SEP

ERPS (G.8032)

STP(IEEE 802.1d), RSTP(IEEE 802.1w), and MSTP(IEEE 802.1s)

ReliabilityEFM OAM (802.3ah)



CFM OAM (802.1ag)

ITU-Y.1731

DLDP

LACP

IP routingStatic route, RIP, RIPng, OSPF
IPv6 featuresNeighbor Discovery (ND)



Path MTU (PMTU)

IPv6 ping, IPv6 tracert, and IPv6 Telnet

MulticastIGMPv1/v2/v3 snooping



Controllable multicast

Interface-based multicast traffic statistics

MLDv1/v2 snooping (Multicast Listener Discovery snooping)

QoS/ACLRate limiting by an interface



Eight queues on each interface

WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms

Re-marking of the 802.1p priority and DSCP priority

Rate limiting in each queue and traffic shaping on interfaces

SecurityPort isolation, port security, and sticky MAC



MFF

Blackhole MAC address entries

Limit on the number of learned MAC addresses

IEEE 802.1x authentication and limit on the number of users on an interface

AAA authentication, RADIUS authentication, HWTACACS+ authentication, and NAC SSH V2.0

Hypertext Transfer Protocol Secure (HTTPS)

CPU defense

Blacklist and whitelist

DHCP relay, DHCP server, DHCP snooping

DHCPv6 relay, DHCPv6 server, DHCPv6 snooping

Lightning protectionService interface: 7 kV
Super Virtual Fabric (SVF)Working as an SVF client that is plug-and-play with zero configuration



Automatically loading the system software package and patches of clients One-click and automatic delivery of service configurations

Supports independent running client

Management and maintenanceiStack



Virtual Cable Test (VCT)

Remote configuration and maintenance using Telnet SNMPv1/v2c/v3

RMON

eSight and web-based NMS

HTTPS

LLDP/LLDP-MED

System logs and multi-level alarms

802.3az EEE

InteroperabilitySupports VBST (Compatible with PVST/PVST+/RPVST) Supports LNP (Similar to DTP)



Supports VCMP (Similar to VTP)

Operating environmentOperating temperature: 0m to 1,800m: 0°C to 45°C; 1,800m to 5,000m (decreases 1°C for every 220m increase in altitude)



Relative humidity: 5% to 95% (noncondensing)

Input voltageAC:



Rated voltage range: 100 V to 240 V AC, 50/60 Hz Maximum voltage range: 90 V to 264 V AC, 47/63 Hz



Thông tin bổ sung

Weight4.5 kg
Dimensions55.5 × 37.5 × 9.0 cm
PoE Type

PoE+

Port

12-24

Rate

GE
