FG-30E 5 x GE RJ45 ports (Including 1 x WAN port, 4 x Switch ports)

Mã sản phẩm: FG-30E

Tình trạng: Còn hàng

Thương hiệu: FORTINET

Hỗ trợ kinh doanh

Ms. Lan
0971156699
Mr Ánh
0327226056
Ms Mỹ
0986671341
Mr Liêm
0934304399

Hỗ trợ kỹ thuật

Mr. Kỳ
0383791490
Mr Toàn
0335709912
Mr Hoàng
0865504891
Mr Công
02432012368

Liên hệ nhận giá tốt

Thông số kỹ thuật

SKU	FG-30E
Firewall	950 Mbps
IPS	300 Mbps
NGFW	200 Mbps
Threat Protection	150 Mbps
Interfaces	5x GE RJ45 ports (Including 1x WAN port, 4x Switch ports)

GE RJ45 Switch Ports	4
GE RJ45 WAN Ports	1
USB Ports	1
Console (RJ45)	1
Wireless Interface	-
System Performance and Capacity
Firewall Throughput	950 Mbps
Firewall Latency (64 byte UDP Packets)	130 μs
Firewall Throughput (Packet per Second)	180 Kpps
Concurrent Sessions (TCP)	900,000
New Sessions/Second (TCP)	15,000
Firewall Policies	5,000
IPsec VPN Throughput (512 byte)	75 Mbps
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	500
SSL-VPN Throughput	35 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode)	100
SSL Inspection Throughput (IPS, avg. HTTPS)	125 Mbps
SSL Inspection CPS (IPS, avg. HTTPS)	120
SSL Inspection Concurrent Session (IPS, avg. HTTPS)	45,000
Application Control Throughput (HTTP 64K)	400 Mbps
CAPWAP Throughput (HTTP 64K)	850 Mbps
Virtual Domains (Default / Maximum)	5 / 5
Maximum Number of FortiSwitches Supported	8
Maximum Number of FortiAPs (Total / Tunnel Mode)	2 / 2
Maximum Number of FortiTokens	500
Maximum Number of Registered FortiClients	200
High Availability Configurations	Active/Active, Active/Passive, Clustering
System Performance
IPS Throughput	300 Mbps
NGFW Throughput	200 Mbps
Threat Protection Throughput	150 Mbps
Dimensions and Power
Height x Width x Length	1.61 x 8.27 x 5.24 inches 41 x 210 x 133 mm
Form Factor	Desktop
Power Required	100–240V AC, 60–50 Hz (External DC Power Adapter)
Maximum Current	100V / 0.6A, 240V / 0.4A
Power Consumption (Average / Maximum)	16 / 19 W
Heat Dissipation	66 BTU/h
Operating Environment and Certifications
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-31–158°F (-35–70°C)
Humidity	10–90% non-condensing
Noise Level	Fan-less 0 dBA
Operating Altitude	Up to 7,400 ft (2,250 m)
Compliance	FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN

Basic Firewall	FG-30E	5 x GE RJ45 ports (Including 1 x WAN port, 4 x Switch ports), Max managed FortiAPs (Total / Tunnel) 2 / 2
1 year bundle	FG-30E-BDL-950-12	FG-30E Hardware plus 1 Year 247 FortiCare and FortiGuard Unified (UTM) Protection (FG-30E & FC-10-0030E-950-02-12)*
1 year License	FC-10-0030E-950-02-12	1 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-30E
3 year bundle	FG-30E-BDL-950-36	FG-30E Hardware plus 3 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-30E & FC-10-0030E-950-02-36)
3 year License	FC-10-0030E-950-02-36	3 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-30E
5 year bundle	FG-30E-BDL-950-60	FG-30E Hardware plus 5 Year 247 FortiCare and FortiGuard Unified (UTM) Protection (FG-30E & FC-10-0030E-950-02-60)*
5 year License	FC-10-0030E-950-02-60	5 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-30E
