S5735-L10T4X-A-V2

(5/5)

Đánh giá sản phẩm

Huawei CloudEngine S5735-L10T4X-A-V2

Tình trạng: Còn hàng

Giá: Liên hệ

Chi tiết: Huawei CloudEngine S5735-L10T4X-A-V2 (10*10/100/1000BASE-T ports, 4*10GE SFP+ ports, AC power)

Liên hệ nhận giá tốt

Tùy chọn

Thông số kỹ thuật

Thiết bị chuyển mạch Huawei CloudEngine S5735-L10T4X-A-V2 (10*10/100/1000BASE-T ports, 4*10GE SFP+ ports, AC power)

Mô tả Huawei CloudEngine S5735-L10T4X-A-V2

s5735-l10t4x-a-v2

1

One MODE button

2

Eight 10/100/1000BASE-T ports

3

Two 10/100/1000BASE-T ports

4

Four 10GE SFP+ ports

5

One console port

6

One PNP button

NOTICE:

To restore the factory settings and reset the switch, hold down the button for at least 6 seconds.

To reset the switch, press the button.

Resetting the switch will cause service interruption. Exercise caution when you press the PNP button.

7

Ground screw

NOTE:
It is used with a ground cable.

8

AC socket

NOTE:

It is used with an AC power cable.

9

Jack for AC power cable locking strap

NOTE:
The AC power cable locking strap is not delivered with the switch.

-

-

Thông số kỹ thuật Huawei CloudEngine S5735-L10T4X-A-V2

Product ModelCloudEngine S5735-L10T4X-A-V2CloudEngine S5735-L10T4X-TA-V2CloudEngine S5735-L8P2T4X-A-V2CloudEngine S5735-L8P2T4X-TA-V2
Forwarding Performance75Mpps75Mpps75Mpps75Mpps
Switching Capacity2100Gbps/520Gbps100Gbps/520Gbps100Gbps/520Gbps100Gbps/520Gbps
Fixed Ports10 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports10 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports8 x 10/100/1000BASE-T ports(PoE+), 2 x 10/100/1000BASE-T ports,4 x 10 GE SFP+ ports8 x 10/100/1000BASE-T ports(PoE+), 2 x 10/100/1000BASE-T ports,4 x 10 GE SFP+ ports
PoENot supportedNot supportedSupportedSupported
MAC FeaturesMAC address auto-learning and aging
Static, dynamic, and blackhole MAC address entries
Packet filtering based on source MAC addresses
Interface-based MAC address learning limiting
VLAN Features4094 VLANs
Voice VLAN
MUX VLAN
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
IP RoutingStatic route, RIPv1/v2, RIPng, OSPF, OSPFv3
InteroperabilityVBST (compatible with PVST/PVST+/RPVST)
LNP (similar to DTP)
VCMP (similar to VTP)
For detailed interoperability certifications and test reports, click HERE.
