JH325A - HPE FlexNetwork 5130 24G PoE+ 4SFP+ 1-slot HI

JH325A - HPE FlexNetwork 5130 24G PoE+ 4SFP+ 1-slot HI

(24) RJ-45 autosensing 10/100/1000 PoE+ ports Ports 1 - 8 support MACSec (4) SFP+ 10GbE ports (1) port expansion module slot Supports a maximum of 6 SFP+ ports or 2 1/10GBASE-T ports, with optional module

Product Differentiator (long)Layer 3 switch with 24 10/100/1000 PoE+ ports 4 SFP+ and 1 expansion module slots. Supports Intelligent Resilient Framework (IRF) virtual fabric and dual power supplies.

Power Consumption Description650 W (maximum)

Heat Dissipation2217 BTU/hr (3599.66 kJ/hr)

Input Voltage100 - 240 VAC, rated (90 - 264 VAC, max) (depending on power supply chosen)

External I/O Ports(24) RJ-45 autosensing 10/100/1000 PoE+ ports Ports 1 - 8 support MACSec (4) SFP+ 10GbE ports (1) port expansion module slot Supports a maximum of 6 SFP+ ports or 2 1/10GBASE-T ports, with optional module

Latency1000 Mb Latency: < 5 µs 10 Gbps Latency: < 3 µs

Routing/switching Capacity168 Gbps

Stacking CapabilitiesIRF 9 switches

Throughputup to 154.8 Mpps

Memory and Processor2 GB SDRAM Packet buffer size: 4 MB 512 MB flash

PoE Capability740 W PoE+

Management FeaturesIMC - Intelligent Management Center Command-line interface Web browser SNMP manager

Weight (imperial)27.56 lb

Weight (metric)12.5 kg

Product Dimensions (imperial)1.72 x 17.32 x 18.11 in

Product Dimensions (metric)4.37 x 44 x 46 cm
