Product Differentiator (long)Layer 3 switch with 48 10/100/1000 PoE+ ports 4 SFP+ and 1 expansion module slots. Supports Intelligent Resilient Framework (IRF) virtual fabric and dual power supplies.
Power Consumption Description670 W (maximum)
Heat Dissipation2286 BTU/hr (2411.73 kJ/hr)
Input Voltage100 - 240 VAC, rated (90 - 264 VAC, max) (depending on power supply chosen)
External I/O Ports(48) RJ-45 autosensing 10/100/1000 PoE+ ports Ports 1 - 8 support MACSec (4) SFP+ 10GbE ports (1) port expansion module slot Supports a maximum of 6 SFP+ ports or 2 1/10GBASE-T ports, with optional module
Latency1000 Mb Latency: < 5 µs 10 Gbps Latency: < 3 µs
Routing/switching Capacity216 Gbps
Stacking CapabilitiesIRF 9 switches
Throughputup to 190.5 Mpps
Memory and Processor2 GB SDRAM Packet buffer size: 4 MB 512 MB flash
PoE Capability1440 W PoE+
Management FeaturesIMC - Intelligent Management Center Command-line interface Web browser SNMP manager
Weight (imperial)27.56 lb
Weight (metric)12.5 kg
Product Dimensions (imperial)1.72 x 17.32 x 18.11 in
Product Dimensions (metric)4.37 x 44 x 46 cm
