Mã sản phẩm: MGS-5220-8P2X
Tình trạng: Còn hàng
Thương hiệu: PLANET
Hỗ trợ kinh doanh
Ms. Lan
Mr Ánh
Ms Mỹ
Mr Liêm
Hỗ trợ kỹ thuật
Mr. Kỳ
Mr Toàn
Mr Hoàng
Mr Công
Liên hệ nhận giá tốt
Thông số kỹ thuật
Hardware Specifications | |
---|---|
Copper Ports | 8 x 100/1000/2500 BASE-T RJ45 Auto-MDI/MDI-X ports |
SFP/mini-GBIC Slots | 2 x 1/10G BASE-X SFP interfaces with Port-9 to Port-10 |
PoE Injector Port | 8 ports with 802.3at/af PoE injector function with Port-1 to Port-8 |
Console | 1 x RJ45 serial port (115200 , 8, N, 1) |
Switch Architecture | Store-and-Forward |
Switch Fabric | 80Gbps |
Throughput | 59.52Mpps@64Bytes |
Address Table | 16K entries, automatic source address learning and aging |
Shared Data Buffer | 16Mbits |
Flow Control | IEEE 802.3x pause frame for full-duplex Back pressure for half-duplex |
Jumbo Frame | 9KB |
Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
LED | System: Fan Alert (Green), SYS (Green), PWR (Green) 100/1000/2500 BASE-T RJ45 Interfaces (Port 1 to Port 8): 100/1000Mbps LNK/ACT (Green) 2500 Mbps (Orange) PoE-in-Use (Orange) 1/10G Mbps SFP Interfaces (Port 9 to Port 10): 1G LNK/ACT (Green) 10G Mbps (Orange) |
Power Requirements | 100~240V AC, 50/60Hz |
Power Consumption (Full Loading) | 320 watts/1091.9 BTU (max.) |
ESD Protection | 6KV DC |
Dimensions (W x D x H) | 330 x 200 x 43.5 mm, 1U height |
Weight | 2kg |
Power over Ethernet | |
PoE Standard | IEEE 802.3at PoE Plus, PSE |
PoE Power Supply Type | End-span |
PoE Power Output | Per port 54V DC, max. 30.8 watts |
Power Pin Assignment | 1/2(+), 3/6(-) |
PoE Power Budget | 240 watts (max.) @ 25 degrees C 200 watts (max.) @ 50 degrees C |
PoE Ability | PD @ 7 watts: 8 units PD @ 15.4 watts: 8 units PD @ 30.8 watts: 8 units |
