Thông số kỹ thuật
Intel Xeon D-1541
8-core 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI)
16 GB DDR4 ECC UDIMM
Memory Module Pre-installed
16 GB (16 GB x 1)
Total Memory Slots
Maximum Memory Capacity
64 GB (16 GB x 4)
· Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
· For more information on the recommended memory configurations, visit here.
· Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Maximum Drive Bays with Expansion Unit
40 (RX1217/RX1217RP x 2)
Compatible Drive Type* (See all supported drives)
· 3.5" SATA HDD
· 2.5" SATA SSD
Maximum Single Volume Size*
· 1 PB (64 GB memory required, for RAID 6 groups only)
· 200 TB (32 GB memory required)
· 108 TB
Hot Swappable Drive
· It is strongly recommended that you only install drives listed on your device's compatibility list. Storage pool and volume creation processes may fail when using unverified drives. Synology is unable to provide technical support for devices using unsupported components.
· "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
· Each internal volume (may consist of multiple drives) is expandable up to 108 TB (with memory less than 32 GB) or 200 TB (with memory equal to or greater than 32 GB).
· For more information on Peta Volume, visit here.
RJ-45 1GbE LAN Port
4 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port
2 (with Link Aggregation / Failover support)
USB 3.2 Gen 1 Port*
The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
2 x Gen3 x8 slots (x8 link)
exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center.
Form Factor (RU)
Size (Height x Width x Depth)
132.3 mm x 482 mm x 656.5 mm
Rack Installation Support*
4-post 19" rack (Synology Rail Kit - RKS-02)
The rail kit is sold separately
80 mm x 80 mm x 3 pcs
Fan Speed Mode
· Full-Speed Mode
· Cool Mode
· Quiet Mode
Easy Replacement System Fan
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter
Redundant Power Supply
AC Input Power Voltage
100 V to 240 V AC
50/60 Hz, Single Phase
145.79 W (Access)
British Thermal Unit
497.14 BTU/hr (Access)
· Power consumption is measured when it is fully loaded with Synology 8TB HAT5300-8T hard drive(s).
· Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
0°C to 35°C (32°F to 95°F)
-20°C to 60°C (-5°F to 140°F)
5% to 95% RH
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
· Main Unit X 1
· Accessory Pack X 1
· AC Power Cord X 2
· Quick Installation Guide X 1
· DDR4 ECC UDIMM: D4EC-2666-16G
· Expansion Units: RX1217/RX1217RP
· 3.5" SATA HDD: HAT5300
· 2.5" SATA SSD: SAT5210
· M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1
· M.2 SSD Adapter Card: M2D20
· 25GbE Network Interface Card: E25G21-F2
· 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1
· Rail Kit Sliding: RKS-02
· VisualStation: VS360HD
· Surveillance Device License Pack
All memory modules will operate at the maximum frequency specified by the CPU manufacturer.
