SA3200D - Nas Synology SA3200D

Controller

Number of Controller Module

2

CPU

CPU Model

Intel Xeon D-1521

CPU Quantity

1 (per controller)

CPU Architecture

64-bit

CPU Frequency

4-core 2.4 (base) / 2.7 (turbo) GHz

Hardware Encryption Engine (AES-NI)

Memory

System Memory

8 GB DDR4 ECC UDIMM (per controller)

Memory Module Pre-installed

8 GB (8 GB x 1) (per controller)

Total Memory Slots

4 (per controller)

Maximum Memory Capacity

64 GB (16 GB x 4) (per controller)

Notes

·         Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.

·         For more information on the recommended memory configurations, visit here.

·         Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

Drive Bays

12

Maximum Drive Bays with Expansion Unit

36 (RXD1219sas x 2)

Compatible Drive Type* (See all supported drives)

·         3.5" SAS HDD

·         2.5" SAS HDD

·         2.5" SAS SSD

Maximum Single Volume Size*

·         200 TB (32 GB memory required)

·         108 TB

Hot Swappable Drive

Notes

·         "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

·         Each internal volume (may consist of multiple drives) is expandable up to 108 TB (with memory less than 32 GB) or 200 TB (with memory equal to or greater than 32 GB).

External Ports

RJ-45 1GbE LAN Port

2 (with Link Aggregation / Failover support) (per controller)

RJ-45 10GbE LAN Port

1 (per controller)

Expansion Port

1

PCIe

PCIe Expansion

1 x Gen3 x8 slot (x8 link) (per controller)

File System

Internal Drives

·         Btrfs

·         EXT4

Appearance

Form Factor (RU)

2U

Size (Height x Width x Depth)

88 mm x 482 mm x 724 mm

Weight

19.7 kg

Rack Installation Support*

4-post 19" rack (Synology Rail Kit - RKS-02)

Notes

The rail kit is sold separately

Others

System Fan

60 mm x 60 mm x 2 pcs

Fan Speed Mode

·         Full-Speed Mode

·         Cool Mode

·         Quiet Mode

Easy Replacement System Fan

Power Recovery

Noise Level*

51.3 dB(A)

Power Supply Unit / Adapter

500 W

Redundant Power Supply

AC Input Power Voltage

100 V to 240 V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption*

417.48 W (Access)

British Thermal Unit

1425.45 BTU/hr (Access)

Notes

·         Noise Level Testing Environment: Fully loaded with Seagate ST8000NM0075 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology server at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.

·         Power consumption is measured when it is fully loaded with Seagate ST3600057SS hard drive(s).

Temperature

Operating Temperature

0°C to 35°C (32°F to 95°F)

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Relative Humidity

5% to 95% RH

Certification

·         FCC

·         CE

·         BSMI

·         EAC

·         CCC

·         VCCI

·         RCM

Warranty

5 Years

Notes

The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

RoHS Compliant

Packaging Content

·         Main Unit X 1

·         Accessory Pack X 1

·         AC Power Cord X 2

·         Quick Installation Guide X 1

Optional Accessories

·         DDR4 ECC UDIMM: D4EC-2666-16G

·         DDR4 ECC UDIMM: D4EC-2666-8G/D4EC-2666-16G

·         Expansion Units: RXD1219sas

·         3.5" SAS HDD: HAS5300

·         25GbE Network Interface Card: E25G21-F2

·         10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1

·         Rail Kit Sliding: RKS-02

·         VisualStation: VS360HD

·         Surveillance Device License Pack

Notes

All memory modules will operate at the maximum frequency specified by the CPU manufacturer.
