XGS-5240-24X2QR - Planet Layer 2+ 24-Port 10G SFP+ + 2-Port 40G QSFP+ Stackable Managed Switch

Mã sản phẩm: XGS-5240-24X2QR

Tình trạng: Còn hàng

Thương hiệu: PLANET

XGS-5240-24X2QR - Planet Layer 2+ 24-Port 10G SFP+ + 2-Port 40G QSFP+ Stackable Managed Switch

Hỗ trợ kinh doanh

Hỗ trợ kỹ thuật

Liên hệ nhận giá tốt

CAM KẾT BÁN HÀNG

Sản Phẩm Chính Hãng 100% Đầy Đủ CO/CQ

Giá Cạnh Tranh Rẻ Nhất Thị Trường

Giao Hàng Trên Toàn Quốc

Hỗ Trợ Kỹ Thuật Chuyên Nghiệp, Nhiệt Tình

Ưu Đãi Lớn Cho Đại Lý Và Dự Án

Chăm Sóc Khách Hàng Trước, Trong và Sau Khi Mua Hàng Tận Tâm.

Thông số kỹ thuật

XGS-5240-24X2QR - Planet Layer 2+ 24-Port 10G SFP+ + 2-Port 40G QSFP+ Stackable Managed Switch

Hardware Specifications
SFP+ Slots24 10GBASE-SR/LR SFP+ interfaces
Compatible with 1000BASE-SX/LX/BX SFP transceiver
QSFP+ Slots2 with each supporting native 40 Gigabit Ethernet and four 10GBASE-SR/LR Ethernet modes
MGMTOne 10/100/1000BASE-T RJ45 port
Console1 RJ45-to-DB9 serial port (9600, 8, N, 1)
USB1 USB 2.0
Switch ArchitectureStore-and-forward
Switch Capacity640Gbps/non-blocking
Switch Throughput476Mpps
Address Table32K MAC address table with auto learning function
Shared Data Buffer4MB
Flow ControlBack pressure for half duplex
IEEE 802.3x pause frame for full duplex
Jumbo Frame9KB
LED IndicatorSystem:
 PWR/DC/MGMT/SYS (Green)
Ports:
 1/10G SFP+ slot: LNK/ACT(Orange/Green)
 40G QSFP+ slot: LNK/ACT (Green)
Dimensions (W x D x H)440 x 318 x 44.6 mm, 1U height
Weight4.3kg
Power Consumption75 watts/210 BTU (maximum)
Power RequirementsAC 100~240V, 50/60Hz
DC 36-72V
Fan3
Layer 3 Functions
Routing ProtocolIPv4 Static routing
IPv6 Static routing
Routing Table64 entries
DHCPDHCP client
DHCP server, default route
DHCP relay
Layer 2 Functions
Port ConfigurationPort disable/enable
1 &10Gbps full duplex mode selection
Flow control disable/enable
Bandwidth control on each port
Port loopback detection
Port StatusDisplay each port’s speed duplex mode, link status, flow control status and
auto negotiation status
VLAN802.1Q tag-based VLAN, up to 4K VLAN entries
802.1ad Q-in-Q (VLAN stacking)
GVRP for VLAN management
Private VLAN Edge (PVE) supported
Protocol-based VLAN
MAC-based VLAN
IP subnet VLAN
Bandwidth ControlTX/RX/both
Link AggregationIEEE 802.3ad LACP/static trunk
Supports 12 trunk groups with 8 ports per trunk group
QoS8 priority queues on all switch ports
Supports strict priority and Weighted Round Robin (WRR) CoS policies
Traffic classification:
- IEEE 802.1p CoS/ToS
- IPv4/IPv6 DSCP
- Port-based WRR
MulticastIPv4 IGMP v1/v2/v3 snooping
IGMP Querier mode support
Ipv6 MLD v1/v2 snooping
MLD Querier mode support
Multicast VLAN Register (MVR)
Access Control ListSupports Standard and Expanded ACL
IP-based ACL/MAC-based ACL
Time-based ACL
Up to 4K entries (3K ingress; 1K egress)
SecurityPort isolation
Supports IP + MAC + port binding
Identification and filtering of L2/L3/L4 based ACL
Defends against DOS or TCP attacks
Suppression of broadcast, multicast and unknown unicast packet
DHCP Snooping, DHCP Option 82
Command line authority control based on user levels
AuthenticationIEEE 802.1x port-based network access control
AAA authentication: TACACS+ and IPv4/IPv6 over RADIUS
