Mã sản phẩm: GS-5220-16T4S2XR
Tình trạng: Còn hàng
Thương hiệu: PLANET
GS-5220-16T4S2XR - Planet L2+ 16-Port 10/100/1000T + 4-Port 100/1000X SFP + 2-Port 10G SFP+ Managed Ethernet Switch
Hỗ trợ kinh doanh
Ms. Lan
Mr Ánh
Ms Mỹ
Mr Liêm
Hỗ trợ kỹ thuật
Mr. Kỳ
Mr Toàn
Mr Hoàng
Mr Công
Liên hệ nhận giá tốt
Thông số kỹ thuật
GS-5220-16T4S2XR - Planet L2+ 16-Port 10/100/1000T + 4-Port 100/1000X SFP + 2-Port 10G SFP+ Managed Ethernet Switch
Hardware Specifications | |
---|---|
Copper Ports | 16 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
SFP/mini-GBIC Slots | 4 100/1000BASE-X SFP interfaces with Port-17 to Port-20 Supports 100/1000Mbps dual mode and DDM |
10Gbps Fiber Uplink Ports | 2 1/10GBASE-SR/LR SFP+ slots |
Console | 1 RJ45 serial port (115200, 8, N, 1) |
Switch Architecture | Store-and-Forward |
Switch Fabric | 80Gbps/non-blocking |
Throughput | 59.5Mpps@64 bytes |
Address Table | 16K entries, automatic source address learning and aging |
Shared Data Buffer | 4 megabits |
Flow Control | IEEE 802.3x pause frame for full-duplex Back pressure for half-duplex |
Jumbo Frame | 9K bytes |
Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
LED | System: SYS (Green) AC (Green) DC (Green) (GS-5220-16T4S2XR Only) Fan Alert ( Red ) Ethernet Interfaces (Port 1 to Port 16): 1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange) 100/1000Mbps SFP Combo Interfaces (Port 17 to Port 20): 1000 (Green), 100 (Orange) 1/10G SFP+ Interfaces (Port 21 to Port 22): 1000 (Green), 10G (Orange) |
Power Requirements | GS-5220-16T4S2X: 100~240V AC, 50/60Hz, 1A GS-5220-16T4S2XR: 100-240V AC, 50/60Hz, 1A 48V DC @ 2A, Range: 36 ~ 60V |
Power Consumption (Full Loading) | GS-5220-16T4S2X: Max. 28.1 Watts/95.8 BTU @ AC 110V Max. 28.4 Watts/96.9 BTU @ AC 220V GS-5220-16T4S2XR: Max. 26.5 Watts/90.4 BTU @ DC 36V Max. 26.9 Watts/91.7 BTU @ DC 48V Max. 27.3 Watts/93.1 BTU @ DC 60V Max. 28.1 Watts/95.8 BTU @ AC 110V Max. 28.4 Watts/96.9 BTU @ AC 220V |
ESD Protection | 6KV DC |
Dimensions (W x D x H) | 440 x 200 x 44.5 mm, 1U high |
Weight | 2754g (GS-5220-16T4S2X) 2789g (GS-5220-16T4S2XR) |
