Mã sản phẩm: GS-5220-24UPL4XR
Tình trạng: Còn hàng
Thương hiệu: PLANET
L3 24-Port 10/100/1000T 802.3bt PoE + 4-Port 10G SFP+ Managed Switch
Hỗ trợ kinh doanh
Ms. Lan
Mr Ánh
Ms Mỹ
Mr Liêm
Hỗ trợ kỹ thuật
Mr. Kỳ
Mr Toàn
Mr Hoàng
Mr Công
Liên hệ nhận giá tốt
Thông số kỹ thuật
L3 24-Port 10/100/1000T 802.3bt PoE + 4-Port 10G SFP+ Managed Switch
Hardware Specifications | |
---|---|
Hardware Version | 3 |
Copper Ports | 24 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
SFP Slots | 4 100/1000BASE-X SFP interfaces, shared with Port-21 to Port-24 Compatible with 100BASE-FX SFP transceiver |
SFP+ Slots | 4 10GBASE-SR/LR SFP+ interfaces (Port-25 to Port-28) Compatible with 1000BASE-SX/LX/BX SFP transceiver |
Console | 1 x RS232-to-RJ45 serial port (115200, 8, N, 1) |
Reset Button | < 5 sec: System reboot > 5 sec: Factory default |
Dimensions (W x D x H) | 440 x 300 x 44.5 mm, 1U height |
Weight | GS-5220-24UPL4X: 5082g GS-5220-24UPL4XR: 5119g |
Power Consumption | GS-5220-24UPL4X: Max. 659.9 watts/2249.2 BTU GS-5220-24UPL4XR: AC: Max.659.9 watts/2249.2 BTU DC: Max. 35.1 watts/119.7 BTU |
Power Requirements – AC | GS-5220-24UPL4X(R): AC 100~240V, 50/60Hz, 10A |
Power Requirements – DC | GS-5220-24UPL4XR: DC 36~60V, 2A |
ESD Protection | 6KV DC |
Fan | 3 smart fans |
LED | System: SYS (Green) AC/PWR (Green) DC (Green) (GS-5220-24UP(L)4XR Only) Ring (Green) Fan1/2/3 Alert (Red) PoE PWR Alert (Red) PoE Ethernet Interfaces (Port-1 to Port-24): bt PoE (Green) , af/at PoE (Amber) Ethernet Interfaces (Port-1 to Port-24): 1000 LNK/ACT (Green), 10/100 LNK/ACT (Amber) 100/1000Mbps SFP Combo Interfaces (Port 21 to Port 24): 1000 (Green), 100 (Amber) 1/10G SFP+ Interfaces (Port-25 to Port-28) : 1G (Green), 10G (Amber) |
Switching | |
Switch Architecture | Store-and-Forward |
Switch Fabric | 128Gbps/non-blocking |
Throughput | 95.23Mpps@64Bytes |
Address Table | 16K entries, automatic source address learning and aging |
Shared Data Buffer | 32M bits |
SDRAM | 512Mbytes |
Flash Memory | 64Mbytes |
Jumbo Frame | 10K bytes |
Flow Control | IEEE 802.3x pause frame for full duplex Back pressure for half duplex |
Power over Ethernet | |
PoE Standard | 802.3bt PoE++ PSE Type-4 and Type-4 PSE Backward compatible with IEEE 802.3af/802.3at PoE PSE |
PoE Power Supply Type | ■ 802.3bt PoE++ ■ UPoE ■ End-span ■ Mid-span ■ Force |
PoE Power Output | Per port 52~54V DC - 802.3bt Type-4 mode, Port-1 to Port-8: maximum 90 watts - 802.3bt Type-3 mode, Port-9 to Port-24: maximum 60 watts - UPoE mode, Port-1 to Port-8: maximum 95 watts - UPoE-mode, Port-9 to Port-24: maximum 72 watts - End-span mode: maximum 36 watts - Mid-span mode: maximum 36 watts - Force mode: maximum 60 watts |
Power Pin Assignment | ■ 802.3bt : 1/2(-), 3/6(+),4/5(+), 7/8(-) ■ UPoE : 1/2(-), 3/6(+),4/5(+), 7/8(-) ■ End-span : 1/2(-), 3/6(+) ■ Mid-span : 4/5(+), 7/8(-) |
PoE Power Budget | GS-5220-24UPL4X(R): 600 watts (max.) |
PoE Ability PD @ 15 watts | GS-5220-24UPL4X(R): 24 units |
PoE Ability PD @ 30 watts | GS-5220-24UPL4X(R): 20 units |
PoE Ability PD @ 60 watts | GS-5220-24UPL4X(R): 10 units |
