UC3200- Synology Unified Controller UC3200

Mã sản phẩm: UC3200

Tình trạng: Còn hàng

Thương hiệu: SYNOLOGY

UC3200- Synology Unified Controller UC3200

Hỗ trợ kinh doanh

Hỗ trợ kỹ thuật

Liên hệ nhận giá tốt

CAM KẾT BÁN HÀNG

Sản Phẩm Chính Hãng 100% Đầy Đủ CO/CQ

Giá Cạnh Tranh Rẻ Nhất Thị Trường

Giao Hàng Trên Toàn Quốc

Hỗ Trợ Kỹ Thuật Chuyên Nghiệp, Nhiệt Tình

Ưu Đãi Lớn Cho Đại Lý Và Dự Án

Chăm Sóc Khách Hàng Trước, Trong và Sau Khi Mua Hàng Tận Tâm.

Thông số kỹ thuật

Controller

Number of Controller Module

2

CPU

CPU Model

Intel Xeon D-1521



CPU Quantity

1 (per controller)



CPU Architecture

64-bit



CPU Frequency

4-core 2.4 (base) / 2.7 (turbo) GHz



Hardware Encryption Engine (AES-NI)



Memory

System Memory

8 GB DDR4 ECC UDIMM (per controller)



Memory Module Pre-installed

8 GB (8 GB x 1) (per controller)



Total Memory Slots

4 (per controller)



Maximum Memory Capacity

64 GB (16 GB x 4) (per controller)



Notes

·         Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

·         Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.

Storage

Drive Bays

12



Maximum Drive Bays with Expansion Unit

36 (RXD1219sas x 2)



Compatible Drive Type* (See all supported drives)

·         3.5" SAS HDD

·         2.5" SAS HDD

·         2.5" SAS SSD



Maximum Single Volume Size*

108 TB



Hot Swappable Drive




Notes

·         It is strongly recommended that you only install drives listed on your device's compatibility list. Storage pool and volume creation processes may fail when using unverified drives. Synology is unable to provide technical support for devices using unsupported components.

·         "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

·         Each internal volume (may consist of multiple drives) is expandable up to 108TB.

External Ports

RJ-45 1GbE LAN Port

2 (with Link Aggregation / Failover support) (per controller)



RJ-45 10GbE LAN Port

1 (per controller)

PCIe

PCIe Expansion

1 x Gen3 x8 slot (x8 link) (per controller)

File System

Internal Drives

Btrfs

Appearance

Size (Height x Width x Depth)

88 mm x 430.5 mm x 692 mm



Size (Height x Width x Depth) (with server ears)

88 mm x 482 mm x 724 mm



Weight

19.7 kg



Rack Installation Support*

4-post 19" rack (Synology Rail Kit - RKS-02)



Notes

The rail kit is sold separately

Others

System Fan

60 mm x 60 mm x 2 (per controller)



Fan Speed Mode

·         Full-Speed Mode

·         Cool Mode

·         Quiet Mode



Easy Replacement System Fan




Power Recovery




Noise Level*

51.3 dB(A)



Power Supply Unit / Adapter

500W



Redundant Power Supply




AC Input Power Voltage

100 V to 240 V AC



Power Frequency

50/60Hz, Single Phase



Power Consumption*

417.48 W (Access)



British Thermal Unit

1425.45 BTU/hr (Access)



Notes

·         Power consumption is measured when it is fully loaded with Seagate ST3600057SS hard drive(s).

·         Noise Level Testing Environment: Fully loaded with Seagate ST8000NM0075 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology server at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.

Temperature

Operating Temperature

0°C to 35°C (32°F to 95°F)



Storage Temperature

-20°C to 60°C (-5°F to 140°F)



Relative Humidity

5% to 95% RH

Certification

·         EAC

·         VCCI

·         CCC

·         RCM

·         KC

·         FCC

·         CE

·         BSMI

Warranty

5 Years



Notes

The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

RoHS Compliant

Packaging Content

·         Main Unit X 1

·         Accessory Pack X 1

·         AC Power Cord X 2

·         Quick Installation Guide X 1

Optional Accessories

·         DDR4 ECC UDIMM: D4EC-2666-8G/D4EC-2666-16G

·         Expansion Units: RXD1219sas

·         3.5" SAS HDD: HAS5300

·         25GbE Network Interface Card: E25G21-F2

·         10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1

·         Rail Kit Sliding: RKS-02



Notes

All memory modules will operate at the maximum frequency specified by the CPU manufacturer.
