Thông số kỹ thuật

CS-KIT-MINI-K9 - Cisco Webex Room Kit Mini

Optional hardware components

●  HDMI presentation cable 8 m/26.2 ft
●  4 m/13 ft USB cable for USB pass-through feature
●  Screen Mount Kit

Bandwidth

●  Up to 6 Mbps point to point

Minimum bandwidth for resolution/frame rate

H.264:

●  720p30 from 768 kbps
●  720p60 from 1152 kbps
●  1080p30 from 1472 kbps
●  1080p60 from 2560 kbps

Firewall traversal

●  Cisco Expressway™ technology
●  H.460.18, H.460.19 firewall traversal

Video standards

●  H.264

Video inputs

●  One HDMI output supports formats up to maximum 4K (3840 x 2160) at 30 fps,
●  including HD1080p60
●  Consumer Electronics Control (CEC) 2.0

Video outputs

●  1 HDMI output supports formats up to 3840 x 2160p60 (4Kp60)
●  Live video resolutions (encode and decode) up to 1920 x 1080p30 and p60 (HD1080p)
●  Consumer Electronics Control (CEC) 2.0

Audio standards

●  G.711, G.722, G.722.1, G.729, AAC-LD, and Opus

Audio features

●  High-quality 20 kHz audio
●  Automatic Gain Control (AGC)
●  Automatic noise reduction
●  Active lip synchronization

Audio inputs

●  One audio in from HDMI
●  Internal microphones

Speakers (integrated)

●  High-quality speakers: full range speaker plus dual woofers in balanced configuration
●  Frequency response 100 Hz to 20 kHz
●  Amplifier power: 24W
●  Max output level SPL 84 dB

MultiSite

●  H.239 (H.323) dual stream
●  Binary Floor Control Protocol (BFCP) (SIP) dual stream
●  Supports resolutions up to 3840 x 2160p5

Dual stream

●  One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps, including HD1080p60
●  Consumer Electronics Control (CEC) 2.0

Wireless sharing

●  Webex app (up to 3840 x 2160p5)
●  Cisco Intelligent Proximity client (up to 1920 x 1080p5)

Multipoint support

●  4-way embedded SIP/H.323 conferencing capability with MultiSite option

MultiSite features (embedded multipoint)*

●  Adaptive SIP/H.323 MultiSite:

◦    3-way resolution up to 1080p30 + content up to 1080p15

◦    4-way resolution up to 720p30 + content up to 1080p15

●  Full individual audio and video transcoding
●  H.323/SIP/VoIP in the same conference
●  Support for presentation (H.239/BFCP) from any participant at resolutions up to 3840 x 2160p5
●  Best impression (automatic continuous presence layouts)
●  Encryption and dual stream from any site

Protocols

●  H.323
●  SIP
●  Cisco Webex

Embedded encryption

●  H.323 and SIP point to point
●  Standards-based: H.235 v3 and Advanced Encryption Standard (AES)
●  Automatic key generation and exchange

IP network features

●  DNS lookup for service configuration
●  Differentiated services (Quality of Service [QoS])
●  IP-adaptive bandwidth management (including flow control)
●  Automatic gatekeeper discovery
●  Dynamic playout and lip-sync buffering
●  H.245 Dual-Tone Multifrequency (DTMF) tones in H.323
●  RFC 4733 DTMF tones in SIP
●  Date and time support using Network Time Protocol (NTP)
●  Media adaptation and resilience
●  Uniform Resource Identifier (URI) dialing
●  Dynamic Host Configuration Protocol (DHCP)
●  802.1X network authentication
●  802.1Q Virtual LAN
●  802.1p (QoS and Class of Service [CoS])

Call control

●  Cisco Unified Communications Manager (Unified CM)

◦    Native registration with Unified CM

◦    Requires Unified CM Version 9.1(2) or later with device pack Room Kit Mini

●  Cisco Expressway

◦    Native registration with Expressway

●  Cisco Webex Service
●  Third-party H.323 gatekeepers and standards-based SIP proxies

IPv6 network support

●  Single call stack support for both H.323 and SIP
●  Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ
●  Support for both static and automatic IP configuration (stateless address auto configuration)

Security features

●  Management using HTTPS and SSH
●  IP administration password
●  Menu administration password
●  Disable IP services
●  Network settings protection
●  Privacy cover

Network interfaces

●  One Ethernet (RJ-45) 10/100/1000 for LAN
●  One Ethernet (RJ-45) for Cisco Touch 10 direct pairing
●  Wi-Fi 802.11a/b/g/n/ac 2.4 GHz/5 GHz, 2x2 MIMO

Note: Due to compliance regulations, it is required that 802.11d is enabled in the access point for the product to operate properly within 5725 MHz – 5875 MHz.

Using a Wi-Fi connection is a flexible option, however an Ethernet connection is always preferred for high performance.

USB pass-through

●  Ability to provide video, microphone, and speakers over one USB cable to a connected computer
●  720p video resolution

Other interfaces

●  1 USB 2.0 port type A
●  1 USB 2.0 port type C
●  1 USB port
●  Factory reset pinhole

Power

●  100 to 240 VAC, 50/60 Hz, 12V DC input
●  Average 20W, peak 70W
●  Must be used with power supply FSP FSP070-AHAN2 or AcBel ADF019

Operating temperature and humidity

●  0°C to 35°C (32°F to 104°F) ambient temperature
●  10% to 90% Relative Humidity (RH)

Storage and transport temperature

●  -20°C to 60°C (-4°F to 140°F) at RH 10% to 90% (non condensing)

PRODUCT NAME

PART NUMBER

COMPLIANCE MODEL NUMBER

Webex Room Kit Mini – Upfront pricing (GPL**)

●  Webex Room Kit Mini Unit
●  Webex Room Navigator

CS-KIT-MINI-K9

CS-KIT-MINI+

CS-T10-TS+



TTC7-26

TTC5-15

Webex Room Kit Mini – No radio

●  Webex Room Kit Mini Unit
●  Webex Room Navigator

CS-KIT-MINI-NR-K9

CS-KIT-MINI-NR+

CS-T10-TS+



TTC7-26

TTC5-15

Webex Room Kit Mini – TAA

●  Webex Room Kit Mini Unit
●  Webex Room Navigator

CS-KIT-MINI-K9++

CS-KIT-MINI-UNIT++ or

CS-KIT-MINI-NR++

CS-T10-TS+



TTC7-26



TTC5-15

Webex Room Kit Mini – No encrytption

●  Webex Room Kit Mini Unit
●  Webex Room Navigator

CS-KIT-MINI-K7

CS-KIT-MINI-NR-K7+

CS-T10-TS+



TTC7-26

TTC5-15

Webex Room Kit Mini – Bundle SKU

●  Webex Room Kit Mini Unit
●  Option of adding SMP+, Multisite and
●  Remote Monitoring

CS-KIT-MINI-BUN



OPTIONS

USB cable (type A connector)

CAB-USBC-4M-GR



Screen Mount Kit

CS-KIT-MINI-SMK



Cisco Table Multi-connector 4K, 9 meters

CAB-HDMI-MUL4K-9M



Presentation cable 8 m 4kp30 certified (HDMI)

CAB-PRES-2HDMI-GR



SOFTWARE OPTIONS – ORDERED SEPARATELY

Remote Monitoring

L-ROOM-RM (L-TP-RM)



MultiSite (embedded multipoint)

L-KITMINI-MS (L-ROOM-PAK)



SPARES

Webex Room Kit Mini – Upfront (GPL) – SPARE

CS-KIT-MINI=

TTC7-26

Webex Room Kit Mini – No radio – SPARE

CS-KIT-MINI-NR=

TTC7-26

Webex Room Kit Mini – No encryption – SPARE

CS-KIT-MINI-K7=

TTC7-26

Power Supply for Room Kit Mini

PSU-12VDC-70W-GR=

FSP070-AHAN2, ADF019

Webex Room Navigator control unit

CS-T10-TS+

TTC5-15

Screen Mount Kit for Room Kit

CS-KIT-MINI-SMK=



Wall Mount Kit for Room Kit

CS-KIT-MINI-WMK=



USB cable (type A connector)

CAB-USBC-4M-GR=



Webex Room Kit Mini (unit) – SPARE

CS-KIT-MINI=

TTC7-26

** GPL = Global Price List
