Mã sản phẩm: S5735-L10T4X-TA-V2
Tình trạng: Còn hàng
Thương hiệu: HUAWEI
Thiết bị chuyển mạch Huawei CloudEngine S5735-L10T4X-TA-V2 (10*10/100/1000BASE-T ports, 4*10GE SFP+ ports, HTM, AC power, Only for Overseas)
Hỗ trợ kinh doanh
Ms. Lan
Mr Ánh
Ms Mỹ
Mr Liêm
Hỗ trợ kỹ thuật
Mr. Kỳ
Mr Toàn
Mr Hoàng
Mr Công
Liên hệ nhận giá tốt
Thông số kỹ thuật
Thiết bị chuyển mạch Huawei CloudEngine S5735-L10T4X-TA-V2 (10*10/100/1000BASE-T ports, 4*10GE SFP+ ports, HTM, AC power, Only for Overseas)
Mô tả Huawei CloudEngine S5735-L10T4X-TA-V2
1 | One MODE button | 2 | Eight 10/100/1000BASE-T ports |
3 | Two 10/100/1000BASE-T ports | 4 | Four 10GE SFP+ ports |
5 | One console port | 6 | One PNP button NOTICE: To restore the factory settings and reset the switch, hold down the button for at least 6 seconds. To reset the switch, press the button. Resetting the switch will cause service interruption. Exercise caution when you press the PNP button. |
7 | Ground screw NOTE: It is used with a ground cable. | 8 | AC socket NOTE: It is used with an AC power cable. |
9 | Jack for AC power cable locking strap NOTE: The AC power cable locking strap is not delivered with the switch. | - | - |
Thông số kỹ thuật
Product Model | CloudEngine S5735-L10T4X-A-V2 | CloudEngine S5735-L10T4X-TA-V2 | CloudEngine S5735-L8P2T4X-A-V2 | CloudEngine S5735-L8P2T4X-TA-V2 |
Forwarding Performance | 75Mpps | 75Mpps | 75Mpps | 75Mpps |
Switching Capacity2 | 100Gbps/520Gbps | 100Gbps/520Gbps | 100Gbps/520Gbps | 100Gbps/520Gbps |
Fixed Ports | 10 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports | 10 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports | 8 x 10/100/1000BASE-T ports(PoE+), 2 x 10/100/1000BASE-T ports,4 x 10 GE SFP+ ports | 8 x 10/100/1000BASE-T ports(PoE+), 2 x 10/100/1000BASE-T ports,4 x 10 GE SFP+ ports |
PoE | Not supported | Not supported | Supported | Supported |
MAC Features | MAC address auto-learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses Interface-based MAC address learning limiting | |||
VLAN Features | 4094 VLANs Voice VLAN MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports | |||
IP Routing | Static route, RIPv1/v2, RIPng, OSPF, OSPFv3 | |||
Interoperability | VBST (compatible with PVST/PVST+/RPVST) LNP (similar to DTP) VCMP (similar to VTP) For detailed interoperability certifications and test reports, click HERE. |
