CÔNG TY CỔ PHẦN DỊCH VỤ CÔNG NGHỆ DATECH
Mã sản phẩm: SA3600
Tình trạng: Còn hàng
Thương hiệu: SYNOLOGY
SA3600 - Nas Synology SA3600
Hỗ trợ kinh doanh
Ms. Lan
Ms Mỹ
Mr Liêm
Hỗ trợ kỹ thuật
Mr. Kỳ
Mr Bảng ( CN Sài Gòn )
Mr Toàn
Liên hệ nhận giá tốt
Thông số kỹ thuật
CPU | CPU Model | Intel Xeon D-1567 |
CPU Quantity | 1 | |
CPU Architecture | 64-bit | |
CPU Frequency | 12-core 2.1 (base) / 2.7 (turbo) GHz | |
Hardware Encryption Engine (AES-NI) | ||
Memory | System Memory | 16 GB DDR4 ECC RDIMM |
Memory Module Pre-installed | 16 GB (16 GB x 1) | |
Total Memory Slots | 4 | |
Maximum Memory Capacity | 128 GB (32 GB x 4) | |
Notes | · For more information on memory upgrade limitations, visit here. · Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. · For more information on the recommended memory configurations, visit here. · Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. | |
Storage | Drive Bays | 12 |
Maximum Drive Bays with Expansion Unit | 96 (RX1222sas/RX1217sas x 7) / 180 (RX2417sas x 7) | |
Compatible Drive Type* (See all supported drives) | · 3.5" SAS HDD · 2.5" SAS HDD · 2.5" SAS SSD · 3.5" SATA HDD · 2.5" SATA HDD · 2.5" SATA SSD | |
Maximum Single Volume Size* | · 1 PB (64 GB memory required, for RAID 6 groups only) · 200 TB (32 GB memory required) · 108 TB | |
Hot Swappable Drive | ||
Notes | · "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. · Each internal volume (may consist of multiple drives) is expandable up to 108 TB (with memory less than 32 GB) or 200 TB (with memory equal to or greater than 32 GB). · For more information on Peta Volume, visit here. | |
External Ports | RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
RJ-45 10GbE LAN Port | 2 (with Link Aggregation / Failover support) | |
USB 3.2 Gen 1 Port* | 2 | |
Expansion Port | 1 | |
Notes | The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. | |
PCIe | PCIe Expansion | 2 x Gen3 x8 slots (x8 link) |
File System | Internal Drives | · Btrfs · EXT4 |
External Drives | · Btrfs · EXT4 · EXT3 · FAT · NTFS · HFS+ · exFAT | |
Notes | exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center. | |
Appearance | Form Factor (RU) | 2U |
Size (Height x Width x Depth) | 88 mm x 482 mm x 724 mm | |
Weight | 14.5 kg | |
Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - RKS-02) | |
Notes | The rail kit is sold separately | |
Others | System Fan | 80 mm x 80 mm x 4 pcs |
Fan Speed Mode | · Full-Speed Mode · Cool Mode · Quiet Mode | |
Easy Replacement System Fan | ||
Power Recovery | ||
Noise Level* | 49.8 dB(A) | |
Scheduled Power On / Off | ||
Wake on LAN / WAN | ||
Power Supply Unit / Adapter | 500 W | |
Redundant Power Supply | ||
AC Input Power Voltage | 100 V to 240 V AC | |
Power Frequency | 50/60 Hz, Single Phase | |
Power Consumption* | 156.23 W (Access) | |
British Thermal Unit | 533.08 BTU/hr (Access) | |
Notes | · Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). · Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8% | |
Temperature | Operating Temperature | 0°C to 35°C (32°F to 95°F) |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
Relative Humidity | 5% to 95% RH | |
Certification | · FCC · CE · BSMI · EAC · CCC · KC · VCCI · RCM | |
Warranty | 5 Years | |
Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) | |
Environment | RoHS Compliant | |
Packaging Content | · Main Unit X 1 · Accessory Pack X 1 · AC Power Cord X 2 · Quick Installation Guide X 1 | |
Optional Accessories | · DDR4 ECC RDIMM: D4RD-2666-16G*/D4RD-2666-32G · Expansion Units: RX2417sas/RX1222sas/RX1217sas · 3.5" SAS HDD: HAS5300 · 3.5" SATA HDD: HAT5300 · 2.5" SATA SSD: SAT5210 · M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1 · M.2 SSD Adapter Card: M2D20 · 25GbE Network Interface Card: E25G21-F2 · 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1 · Rail Kit Sliding: RKS-02 · VisualStation: VS360HD · Surveillance Device License Pack | |
Notes | It is required to use D4RD-2666-16G with identical memory modules of the same capacity and frequency. For more information, visit here. |
